Single Cylinder Compressor
CW.137.001
EAN-Code: 6989141370019
Product Code:CW.137.001
WABCO
- 412 352 026 0
- 412 352 007 0
- 412 352 010 0
- 412 352 006 0
- 412 352 017 0
- 412 352 014 0
Mercedes-Benz
- A 457 130 44 15
- 457 130 44 15
- A 457 130 24 15
- 457 130 24 15
- A 457 130 67 15
- A 457 130 11 15
- 457 130 11 15
- 457 130 17 15
- 457 130 24 15
- 457 130 44 15
- A 457 130 08 15
- 457 130 08 15
- 906 130 08 15
- 457 130 11 15
- 457 130 17 15
- 457 130 24 15
- 457 130 44 15
- A 457 130 17 15
- 457 130 17 15
- 906 130 17 15
- 457 130 24 15
- 457 130 44 15
Daimler
- A 457 130 67 15
Share:
| Brand |
Mercedes-Benz |
|---|---|
| Cylinder Diameter | |
| Swept Volume |
352 cm³ |
| Piston Operating Distance |
62 mm |
| Port 0 |
M30x1.5 |
| Port 2 |
M26x1.5 |
| Port 4 |
M12x1.5 |
| Port 8.1 |
Ø4 mm |
| Port 8.2 |
Ø15.5 mm |
| Port 9 |
M12x1.5 |
| Port 9.1 |
M16x1.5 |
| Port 9.2 |
M16x1.5 |
| Crankshaft Thread |
M20x1.5 LH |
| Number of Cylinders |
1 |
| Cooling Type |
Water |
| With ESS Feature |
YES |
| Water Cooled Valve Plate |
YES |
| Direct Working |
Yes |
| Maximum Operating Pressure |
12.5 bar |
| Weight |
14.7 kg |
